HMX 200 Technical Details

Capacity

200 Kg/Hour

Installed Motor Power

40 KW

Absorbed Electric Power

20 KW

Installed Power For Dryer :

70.000 Kcal/Hour

Absorbed Power For Dryer

60.000 Kcal/Hour

Cooled Water :

12.000 Kcal/Hour at 5 - 12 °C

Circular Die's Diameter

220 mm

HMX 300 Technical Details

Capacity

300 Kg/Hour

Installed Motor Power

50 KW

Absorbed Electric Power

30 KW

Installed Power For Dryer :

105.000 Kcal/Hour

Absorbed Power For Dryer

90.000 Kcal/Hour

Cooled Water :

18.000 Kcal/Hour

Circular Die's Diameter

270 mm



















































HMX 400 Technical Details

Capacity

400 Kg/Hour

Installed Motor Power

95 KW

Absorbed Electric Power

60 KW

Installed Power For Dryer :

200.000 Kcal/Hour

Absorbed Power For Dryer

110.000 Kcal/Hour

Cooled Water :

20.000 Kcal/Hour at 5 - 12 °C

Circular Die's Diameter

350 mm

Length

26 metres

Height

6,5 metres

Width

4 metres



HMX 600 Technical Details

Capacity

600 Kg/Hour

Installed Motor Power

105 KW

Absorbed Electric Power

70 KW

Installed Power For Dryer :

250.000 Kcal/Hour

Absorbed Power For Dryer

150.000 Kcal/Hour

Cooled Water :

30.000 Kcal/Hour at 5 - 12 °C

Circular Die's Diameter

400 mm

Length

26 metres

Height

6,5 metres

Width

4 metres



HMX 800 Technical Details

Capacity

800 Kg/Hour

Installed Motor Power

115 KW

Absorbed Electric Power

80 KW

Installed Power For Dryer :

300.000 Kcal/Hour

Absorbed Power For Dryer

210.000 Kcal/Hour

Cooled Water :

50.000 Kcal/Hour at 5 - 12 °C

Circular Die's Diameter

420 mm

Length

26 metres

Height

6,5 metres

Width

4,5 metres



HMX 1000 Technical Details

Capacity

1000 Kg/Hour

Installed Motor Power

120 KW

Absorbed Electric Power

90 KW

Installed Power For Dryer :

400.000 Kcal/Hour

Absorbed Power For Dryer

300.000 Kcal/Hour

Cooled Water :

5 -12°C with 60.000 Kcal/Hour

Circular Die's Diameter

450 mm

Length

31,5 metres

Height

7,4 metres

Width

4.5 metres



HMX 1500 Technical Details

Capacity

1500 Kg/Hour

Installed Motor Power

140 KW

Absorbed Electric Power

100 KW

Installed Power For Dryer :

450.000 Kcal/Hour

Absorbed Power For Dryer

360.000 Kcal/Hour

Cooled Water :

5-12°C with 80.000 Kcal/Hour

Circular Die's Diameter

520 mm

Length

36 metres

Height

7,5 metres

Width

4,5 metres



HMX 2250 Technical Details

Capacity

2250 Kg/Hour

Installed Motor Power

160 KW

Absorbed Electric Power

120 KW

Installed Power For Dryer :

550.000 Kcal/Hour

Absorbed Power For Dryer

450.000 Kcal/Hour

Cooled Water :

5-12°C with 100.000 Kcal/Hour

Circular Die's Diameter

620 mm 1 Pc

Length

50 metres

Height

8 metres

Width

4,5 metres



HMX 3000 Technical Details

Capacity

3000 Kg/Hour

Installed Motor Power

200 KW

Absorbed Electric Power

170 KW

Installed Power For Dryer :

800.000 Kcal/Hour

Absorbed Power For Dryer

700.000 Kcal/Hour

Cooled Water :

5-12°C with 120.000 Kcal/Hour

Circular Die's Diameter

720 mm 1 Pc

Length

50 metres

Height

8,6 metres

Width

4,5 metres



HMX 4500 Technical Details

Capacity

4500 Kg/Hour

Installed Motor Power

300 KW

Absorbed Electric Power

220 KW

Installed Power For Dryer :

1.000.000 Kcal/Hour

Absorbed Power For Dryer

900.000 Kcal/Hour

Cooled Water :

5 -12°C with 180.000 Kcal/Hour

Circular Die's Diameter

620 mm 2 Pcs

Length

52 metres (Without Silos)

Height

8,9 metres

Width

5,5 metres



HMX 6000 Technical Details

Capacity

6000 Kg/Hour

Installed Motor Power

350 KW

Absorbed Electric Power

270 KW

Installed Power For Dryer :

1,250.000 Kcal/Hour

Absorbed Power For Dryer

1,100.000 Kcal/Hour

Cooled Water :

5-12°C with 250.000 Kcal/Hour

Circular Die's Diameter

670 mm 2 Pcs

Length

56 metres

Height

8,9 metres

Width

5,5 metres
